Macromatic LCP2D100 Liquid Level Control Relay
Replacement Part for Accu-Tab® Units - 1030, 3070AT, 3140AT, 3500
Product Overview:
The Macromatic LCP2D100 Liquid Level Control Relay is an essential component for monitoring and controlling the liquid levels in Accu-Tab® chlorination systems. Designed for pump-down (drain) operation, this relay ensures optimal liquid level management, preventing overflow and maintaining consistent system performance.
Key Features & Specifications:
Control Type: Dual-probe pump-down operation (drain control).
Input Voltage: 120V AC, standard power compatibility.
Output Configuration: SPDT (Single-Pole Double-Throw) relay, 10A contact rating.
Sensitivity Adjustment: 4.7KΩ - 100KΩ, accommodating different liquid conductivities.
Time Delay: 1-second fixed delay to prevent rapid cycling and ensure stable operation.
Base Design: 8-pin octal socket for easy installation and replacement.
Operating Temperature: -28°C to 65°C (-18°F to 149°F).
Certifications: UL and cUL Recognized, ensuring compliance with safety standards.
Probe Voltage: Pulsed 5V DC to prevent electroplating and extend probe life.
LED Indicators:
Green ON – Power applied.
Flashing Red – Timing delay in progress.
Red ON – Relay is energized.
Output Contacts Ratings:
10A @ 240V AC
7A @ 28V DC
¼ HP @ 120V AC (Normally Open)
For installation guidance, refer to the Macromatic LCP2D100 Installation Manual.
| Unit Compatibility | 1030AT, 3070AT, 3140AT, 3075 Powerbase, 3500 Powerbase |
|---|
